Specifications

CPU QCA9531

CPU core count 1

CPU nominal frequency 650 MHz

Dimensions 443 x 382 x 44 mm

License level 5

Operating System  RouterOS

Size of RAM 64 MB

Storage size 16 MB

Storage type FLASH

Tested ambient temperature -20°C to 60°C

Powering

Number of AC inputs 1

AC input range 100-240

Max power consumption 800 W

Max power consumption without attachments 85 W

PoE-out

PoE-out ports 48 ports with 802.3af/at and passive modes

PoE out 802.3af/at

Max out per port output (input < 30 V) 1000 mA

Max out per port output (input > 30 V) 570 mA

Total output current 27A at 26V OR 13.2A at 53V

Total output power 700W

Ethernet

10/100 Ethernet ports 1

10/100/1000 Ethernet ports 48

Fiber

SFP+ ports 4

Number of 40G QSFP+ ports 2

Peripherals

Serial port RJ45

Other

CPU temperature monitor Yes

Current Monitor Yes

PCB temperature monitor Yes

Voltage Monitor Yes
